PCB Fabrication Services in Shenzhen
Rigid · Flex · HDI · Impedance-controlled — up to 42 layers, with DFM and quick-turn prototyping.
BELI Technologies is a Shenzhen-based PCB fabricator producing rigid, flexible, HDI, and impedance-controlled boards up to 42 layers. Every order includes DFM (Design for Manufacturability) analysis to optimize your design for yield and cost before production begins.
BELI Technologies offers comprehensive PCB fabrication services supporting rigid PCB, flexible circuits, HDI, and impedance-controlled boards. Our state-of-the-art facility can produce boards from 1 to 42 layers using a wide range of materials including FR-4, Polyimide, Aluminum, Ceramic, and Rogers high-frequency substrates.
Our DFM (Design for Manufacturability) analysis ensures your boards are optimized for production before manufacturing begins, reducing costs and time-to-market.
Boards are produced with inner-layer line width and spacing down to 3.0/3.0 mil, copper weights from 0.5 to 6.0 oz, aspect ratios up to 11:1, and board thicknesses from 0.2 mm to 8.0 mm on panels up to 18″ × 24″. Surface finishes include HASL, lead-free HASL, ENIG, immersion silver, and immersion tin, with solder mask and silkscreen in any color on request.
Quick-turn prototypes ship in as fast as 24 hours for 1–2 layer boards and 3–7 working days for multilayer designs, with no minimum order quantity — so you can validate a single board before committing to volume. Every board is electrically tested and AOI-inspected before shipment, and quotes are returned within 24 hours.
Capabilities & Specifications
| Layers | Up to 42 |
|---|---|
| Min Line Width/Spacing (Inner) | 3.0/3.0 mil |
| Min Line Width/Spacing (Outer) | 4.0/4.0 mil |
| Copper Weight | 0.5 – 6.0 OZ |
| Max Aspect Ratio | 11:1 |
| Board Thickness | 0.2mm – 8.0mm |
| Max Panel Size | 18″ × 24″ |
| Min Hole Diameter | 4 mil |
| Materials | FR-4, High Tg FR-4, Halogen-free, Rogers, Arlon, Taconic, Nelco |
| Surface Treatment | HASL, ENIG, Immersion Silver/Tin, Lead-free HASL |
| Impedance Control | ±10% |
| Workmanship Standard | IPC-A-600 (acceptability of printed boards) |
| Solder Mask / Silkscreen | Any color on request |
Need the full picture? See our complete PCB & SMT manufacturing capability specifications.
